| Camera |
| TV SYSTEM | NTSC / PAL |
| IMAGE SENSOR | 1/4-inch CCD Image Sensor |
| MINIMUM ILLUMINATION | 0.5 Lux F1.2 5600°K
0 Lux with IR-Light (Can be only use 850nm IR-Light) |
| RESOLUTION | 380TVL / 470 TVL ( Enhanced ) |
| POWER SUPPLY | DC12V / 65mA |
| 5.8 GHz Wireless Transmitter |
| Input Voltage | DC 8V ~14V |
| Current Consumption | 65mA (TYPICAL) @ DC12V |
| Antenna Type | Helical |
| Operation temperature & humidity | 0°C ~ +50°C less than 85% |
| Storage temperature & humidity | -20°C ~+70°C less than 90% |
| Channel Frequency | 8 CH |
| Output power @ connector | 13dBm (max) |
| Pre-Emphasis | NTSC and PAL |
| 5.8 GHz Wireless Receiver |
| Operating Frequency | 5.725Ghz ÷ 5.875Ghz (8 User selectable channels) |
| Range (line of sight) | 150 feet (5dBi Antenna) |
| Antenna Type | Omnidirectional |
| Video Format | NTSC & PAL |
| Temperature Range | 0°C ~ 60°C |
| Current Consumption | 120mA @ 12V DC |
| Dimensions | 180mm x 100mm x 32mm |
| Weight | 450g |
| FCC/IC/CE Approved | Yes |
