Long Range Bugging Device STRC-600

Long Range Bugging Device STRC-600 in waterproof case

Introduction

Long Range Bugging Device STRC-600 Eavesdroppers use radio bugging devices as the intelligence is received in real time and is of a very high quality. Microphone technology and high gain circuit design enable these devices to pick up the slightest sound within a room up to few meters away from the installed bug.

The STRC-600 is one of the most powerful room transmitter in our product range. The output power is 18 dbm.

A radio analog room monitoring bug, or simply a bug, is made up of a small spy microphone, connected to a miniature radio transmitter, which picks up any audio signals around it and transmits them towards a radio receiver, aptly placed at a distance which, according to the transmitter's output power, can range within a few tens of meters up to some kilometers; receiver and transmitter must be tuned into the same frequency.

This bugging device is designed for covert audio surveillance. Due to its tiny size the transmitters can be concealed in various items. The STRC-600 spy bug is suitable for the most miniature types of camouflage, making it an indispensable intelligence gathering tool for nearly every scenario.

Application:

  • Room Monitoring
  • Homeland Security
  • Standard Indoor Surveillance Operation
  • Design for Hidden Installation
  • Audio Surveillance or Audio Intercept purposes, to be used by law enforcement agencies
  • Private Investigation

Advantage:

  • Programmable operating frequency with using STV-02
  • Waterproof case
  • Long range
  • Battery low warning
  • Built-in Frequency Synthesizer
  • Small size (without waterproof case)
  • Designed for working with our STV-02 and STV-05 (partially) Digital and Analog Receivers
  • Compatible for operation with another WFM-receivers which are working in the same frequency range as STRC-600 (without possibility to change operating frequency of the mini transmitter).

Specification:

Frequency of the transmitter (setting with using STV-02): 400 MHz ÷ 440 MHz
Frequency setting accuracy (setting with using STV-02)5 kHz
Output Power:+18 dBm
Modulation:WFM
Power Supply:6÷14VDC (External)
Consumption Current120÷60 mA
Antenna:180 mm
Microphone:Knowles
Dimensions with waterproof case:73 x 34 x 11 mm
Dimensions of PCB only:35 x 26 x 7 mm

View Quick startSTRC-600 Quick start
