| | SPECIFICATIONS |
Frequency range: | | 10 Hz - 3 GHz |
Size: | 100 mm high x 68 mm wide x 31 mm deep |
Weight: | 250 g |
Impedance: | 1 * dual purpose BNC Socket 50 Ohms input
for range 1 MHz to 3 GHz
1 Meg Ohm input for range 10 Hz to 50 MHz |
Case: | Stamped aluminum with black anodized finish |
Battery: | Internal 4 x AA 600 mAH NiCd pack |
Power: | 9 VDC 300 mA |
Timebase: | Less than 1 PPM at room temperature |
| |
FEATURES |
- 10 digit Liquid Crystal Display
- Hi-Z low range
- Filter to prevent display of random noise
- Automatic hold
- Measures frequency and period
- LED back light
- Beeper
- Low power consumption (Average 6 hour battery life)
- Hold switch to lock display
- Low battery indicator
- Ultra sensitive synchronous detector 16 section bargraph
to show RF signal strength - High speed 300 MHz direct counter with 0,1 Hz resolution
- 4 selectable gate speeds
|
DATASHEET |
| |
