| | SPECIFICATIONS |
Frequency range: | | 1 MHz -6 GHz |
Size: | 100 mm high x 68 mm wide x 31 mm deep |
Weight: | 230 g |
Impedance:
| 50 Ohms (BNC Socket) |
Case: | Stamped aluminum with black anodized finish |
Battery: | Internal 5 x AA 600 mAH NiCd pack |
Power: | 9 VDC 300 mA |
Timebase: | Less than 1 PPM at room temperature |
| |
FEATURES - Pocket size
- Built-in speaker to output alert tone
- Vibration motor and earphone for silent detection
- 5 section RSSI bargraph to show relative RF signal strength
- Low power consumption (Average 8 hour battery life)
- Supplied with NiCd pack, AC wall charger, short rubber antenna and earphone.
CONTROLS |
SEN Knob - This knob turns the tracer on and adjusts sensitivity.
VIBRATION Switch - This switch selects the tone or vibration alert output. |
